制毡工艺
将玻璃纤维纱短切成一定长度，随机沉降在输送带上，然后用粉剂粘结剂将这些短切纤维粘结在一起，经过烘干、冷却和卷绕，形成短切原丝毡。
玻璃纤维粉剂毡
玻璃纤维粉剂毡是由玻璃纤维原丝经短切后，随机无定向均匀平铺，然后用粉剂粘结剂粘结在一起而制成的片状毡片。可适用于增强UP、VE、EP和PF等。产品幅寛范围 200mm ~ 3120mm,可根据客户的使用要求和习惯，提供不同浸透和分解时间要求的产品。
产品特点
1.拉伸强度高，适用于手糊工艺生产面积较大的制品，树脂浸穿性好，浸透速度快，气泡气容易排除，制品机械强度高，优异的耐酸腐蚀性能。
2.毡质柔软，覆模性好，方便手工撕裂，树脂浸穿性好，浸透速度快，减少辐压次数，树脂消耗少。
应用市场
（汽车顶棚）
AVAILABLE PRODUCTS
Product ID* | Nominal Area Wt. g/m2 | Nominal Area Wt. oz/ft2 | Nominal LOI (%) |
CSMP-100G-XX | 100 | 0.32 | 3.5 |
CSMP-150G-XX | 150 | 0.50 | 3.5 |
CSMP-200G-XX | 200 | 0.70 | 3.0 |
CSMP-300G-XX | 300 | 1.0 | 3.0 |
CSMP-450G-XX | 450 | 1.5 | 2.8 |
CSMP-600G-XX | 600 | 2.0 | 2.6 |
CSMP-800G-XX | 800 | 2.6 | 2.4 |
CSMP-900G-XX | 900 | 3.0 | 2.4 |
PRODUCT DATA
Type of Glass | E-glass glass formulation |
Resin Compatibility | Polyester, Vinyl Ester & Epoxy |
Coupling Agent | Silane |
Binder Type | Powder |
Linear Density (Tex or Yield) | Nominal ± 10% |
Moisture (%) | ≤ 0.20% |
Packaging | Plastic bag wrapped, cylindrical rolls on side, 9 rolls per pallet |
Roll Dimensions | Cylindrical 30cm ( 12 .0” ) DIA x roll widths 15cm (6”) to 320cm (125”) |
Roll Weights | 24 kg (53 lb) to 70 kg (154 lb) |
Pallet Configuration | Stretch Wrapped and Top Protected . Number of rolls and layers vary with roll width |
Storage Recommendations | Stack pallets only one (1) high. Do Not Double Stack |
